At a party this weekend, I had a conversation with someone who believed that the energy needs of the future would be solved by hydrogen. Not hydrogen as the input for nuclear fusion, but hydrogen as a feedstock for fuel cells and combustion engines. It’s not entirely surprising that some people believe this. For years, car companies have been spouting off about hydrogen powered vehicles that will produce only water vapour as emissions. The Chevron game mentioned earlier lets you install ‘hydrogen’ electricity generating capacity. The oversight, of course, is that hydrogen is just an energy carrier. You might as well say that the energy source of the future will be AA batteries.
AA batteries are obviously useful things. They provide 1.5 volts of power that you can carry around with you and use to drive all manner of gadgetry, but they are hardly an energy system unto themselves. The chemicals inside them that create their electrical potential had to be extracted, processed, and combined into a usable form. Inevitably, this process required more energy than is in the batteries at the end. The loss of potential energy is a good trade-off, because we get usable and portable power, but there is no sense in which we can say that AA batteries are an energy system.
A similar trade-off may well eventually be made with hydrogen. We may break down hydrocarbons, sequester the CO2 produced in that process, and use the hydrogen generated as fuel for cars. Alternatively, we might use gobs of electricity to electrolyse water into hydrogen and oxygen. Then, we just need to find a way to store a decent amount of hydrogen safely in a tank small, durable, and affordable enough to put in vehicles; build fleets of vehicles with affordable fuel cells or hydrogen powered internal combustion engines; and develop an infrastructure to distribute hydrogen to all those vehicles.
When you think about it, hydrogen seems less like a solution in itself, and more like the possible end-point of solving a number of prior problems. As far as ground vehicles go, it seems a safer bet to concentrate on improvements to rechargeable battery technology.
Funny, cute, informative
Ontario votes – the winner of this election will decide whether to replace our aging electricity system with dirty, dangerous, and expensive coal and nuclear power or whether Ontario’s future will be fueled by clean alternatives and conservation. Vote for Clean Energy is a strictly non-partisan voter education campaign by five leading environmental groups.
“The hydrogen fuel cell costs nearly 100 times as much
per unit of power produced as an internal-combustion engine.
To be price competitive, “you’ve got to be at a nickel a watt, and
we’re at $4 a watt,’’ says Tim R. Dawsey, a research associate
at Eastman Chemical Company, which makes polymers for fuel
cells. Hydrogen is also about five times as expensive, per unit
of usable energy, as gasoline.”
“Hydrogen could come from the methane in natural gas,
methanol or other hydrocarbon fuel. Natural gas can be reacted
with steam to make hydrogen
and carbon dioxide. Filling fuel cells, however, would preclude
the use of natural gas for its best industrial purpose today: burning
in high-efficiency combined-cycle turbines to generate electricity.
That, in turn, might again lead to more coal use. Combined-
cycle plants can turn 60 percent of the heat of burning
natural gas into electricity; a coal plant converts only about 33
percent. Also, when burned, natural gas produces just over half
as much carbon dioxide per unit of heat as coal does, 117
pounds per million Btu versus 212. As a result, a kilowatt-hour
of electricity made from a new natural gas plant has slightly
over one fourth as much carbon dioxide as a kilowatt-hour
from coal. (Gasoline comes between coal and natural gas, at
157 pounds of carbon dioxide per million Btu.) In sum, it seems
better for the environment to use natural gas to make electricity
for the grid and save coal, rather than turning it into hydrogen
to save gasoline.”
“When natural gas is cracked for hydrogen, about 40 percent
of the original energy potential is lost in the transfer, according
to the DOE Office of Energy Efficiency and Renewable
Energy. Using electricity from the grid to make hydrogen by electrolysis
of water causes a loss of 78 percent.”
“In contrast, pumping a gallon of oil out of the
ground, taking it to a refinery, turning it into gasoline and getting
that petrol to a filling station loses about 21 percent of the
energy potential. Producing natural gas and compressing it in a
tank loses only about 15 percent.”
“For the conventional
gasoline internal-combustion engine, 85 percent of the energy
in the gasoline tank is lost; thus, the whole system, well to tank
combined with tank to wheels, accounts for a total loss of
88 percent… The fuel cell converts about 37 percent of the hydrogen’s
energy value to power for the wheels. The total loss, well to
wheels, is about 78 percent if the hydrogen comes from steamreformed
natural gas. If the source of the hydrogen is electrolysis
from coal, the loss from the well (a mine, actually) to tank
is 78 percent; after that hydrogen runs through a fuel cell, it loses
another 43 percent, with the total loss reaching 92 percent.”
“In a car that employs an electric motor to turn the wheels, a
kilowatt-hour used to recharge batteries will propel the auto
three times as far as if that same kilowatt-hour were instead
used to make hydrogen for a fuel cell.”
“Fuel-cell vehicles emit no greenhouse gases themselves, but the
creation of the hydrogen fuel can be responsible for more
emissions overall than conventional gasoline internalcombustion
engines are.”
“Given
hydrogen’s low density, it is far harder to deliver than, for instance,
natural gas. To move large volumes of any gas requires
compressing it, or else the pipeline has to have a diameter similar
to that of an airplane fuselage. Compression takes work, and
that drains still more energy from the total production process.
Even in this instance, managing hydrogen is trickier than dealing
with other fuel gases. Hydrogen compressed to about 790
atmospheres has less than a third of the energy of the methane
in natural gas at the same pressure, points out a recent study by
three European researchers, Ulf Bossel, Baldur Eliasson and
Gordon Taylor.”
“A related problem is that a truck that could deliver 2,400
kilos of natural gas to a user would yield only 288 kilos of hydrogen
pressurized to the same level, Bossel and his colleagues
find. Put another way, it would take about 15 trucks to deliver
the hydrogen needed to power the same number of cars that
could be served by a single gasoline tanker. Switch to liquid hydrogen,
and it would take only about three trucks to equal the
one gasoline tanker, but hydrogen requires substantially more
effort to liquefy.”
Scientific American 2004
“Storage devices should hold sufficient hydrogen to support today’s minimum acceptable travel range—300 miles—on a tank of fuel in a volume of space that does not compromise passenger or luggage room. They should release it at the required flow rates for acceleration on the highway and operate at practical temperatures. They should be refilled or recharged in a few minutes and come with a competitive price tag. Current hydrogen storage technologies fall far short of these goals.”
“Even at 10,000 psi, the best achievable energy density with current high-pressure tanks (39 grams per liter) is about 15 percent of the energy content of gasoline in the same given volume. Today’s high-pressure tanks can contain only about 3.5 to 4.5 percent of hydrogen by weight.. Also, the current cost of such tanks is 10 or more times higher than what is competitive for autos.”
Scientific American 2007
for cars, not hydrogen, but compressed air. First compressed air cars will be in Canada next year. Will blow the market open.
for boats, not hydrogen, but lead acid batteries. I can’t believe there’s a dude who is using solar panels to make hydrogen to power a motor to drive his sailboat. It’s a boat! Batteries are heavy! It’s a perfect combination.
Tristan,
Compressed air for mobile energy storage
I haven’t heard anything about this since that post was written. I wonder whether things are still moving forward.
Dream of hydrogen car goes down in flames
By Joseph Romm
Ballard — the Canadian fuel-cell company that once hoped to be the “Intel Inside of the hydrogen car revolution — has sold off its automotive fuel-cell business to Daimler and Ford.
You can listen to a good CBC radio story on it, which includes an interview of me (click on “Listen to the Current,” Part 2). You can read Toronto Star columnist Tyler Hamilton on the story here. A Financial Post post piece headlines the story bluntly: “Hydrogen highway hits dead end: Ballard’s talks with potential buyers is admission that dream of hydrogen fuel car is dead: analyst.”
WATER AS FUEL – Using hydrolysis to produce hydrogen and oxygen from water requires more energy than the amount you get back by “combusting” the hydrogen to power a vehicle. This energy deficeit [sic] makes “onboard hydrolysis” vehicles infeasible. (Hydrogen gas and fuel cell powered vehicles already exist that use methods other than “onboard hydrolysis”.)
Electrolysis of Water
By providing energy from a battery, water (H2O) can be dissociated into the diatomic molecules of hydrogen (H2) and oxygen (O2). This process is a good example of the the application of the four thermodynamic potentials.
Hydrogen
While not generally considered a biofuel, I discussed hydrogen in my “Pretenders” piece so I will address it here as well. In my opinion, the most interesting realistic option for hydrogen is as energy storage for excess power. For instance, let’s say you have a neighborhood in which most houses have enough solar panels to produce excess electricity at mid-day. Once the batteries are charged, what else can you do with that excess electricity? If it can’t be diverted to someplace that has a need, then it may make sense to electrolyze water to produce hydrogen. This is not a very efficient process, and not something you would do under normal circumstances, but in this case it could be the best storage option.
Once the hydrogen is produced, it could either be used to fuel stationary fuel cells for the neighborhood when the solar panels aren’t producing, or it could be compressed and used to fuel hydrogen combustion engines.
Summary of problems with fuel cells and hydrogen
There were several reasons for this. For a start, ripping up and replacing the world’s fossil-fuel infrastructure is a huge job. And even were that an easy thing to accomplish, hydrogen itself has drawbacks. Though better than batteries, it stores less energy in a given volume than fossil fuels can manage (see chart 1). More important, it is not a primary fuel. You have to make it from something else.
This can be done by a chemical reaction called steam reforming but, besides steam, the other ingredient of that process is a hydrocarbon of some sort, which rather defeats the object of the exercise. Or it can be done by the electrolysis of water. This has appropriate green credentials as long as the electricity is either from renewable sources or a nuclear-power plant. But the laws of thermodynamics mean that the energy content of the hydrogen which comes out of the process is less than the electricity that went in. This inbuilt inefficiency raises the question “why not simply power the end-use electrically, rather than using hydrogen as an intermediary?”
“Despite Hyundai’s and Toyota’s enthusiasm, few analysts believe cars will be part of this process. The ccc calculates that a battery-powered car charged with electricity from a wind turbine converts 86% of the turbine’s output into forward motion on the road. For a fuel-cell car, it is 40-45%. Hydrogen cars also suffer from a chicken-and-egg problem. Unlike the battery-powered variety, they cannot be refuelled at home. Yet roadside refuelling stations for them are scarce, and are likely to remain so while the cars themselves remain rare.”
Hydrogen cannot be substituted into parts of the methane pipeline network at high concentrations because it embrittles the materials that those pipes are made of. This means that significant infrastructure would need to be built to move hydrogen around, which EVs don’t need because most buildings already have electricity. Low-pressure hydrogen is 4× less energy dense on a volumetric basis than methane, meaning some of the useful functions of methane pipelines cannot be replicated with hydrogen. Medium and high-pressure pipes would need to be replaced, but every compressor in the network would also need to be replaced either way, partly because the energy consumption to move it would increase by a factor of three.
Blue hydrogen sounds good in theory but there is a problem. It doesn’t exist. More specifically, carbon capture and storage (CCS) doesn’t meaningfully exist at commercial scale. If CCS is viable or needs to become viable, then governments should mandate all large CO2 streams (like already existing power plants and chemical operations) to use CCS. This would largely solve the climate crisis. However, fossil fuel companies do not promote mandatory CCS because they know that it would make the use of their hydrocarbon products too expensive, thus destroying their business, and accelerating the transition to non-hydrocarbon energy technologies. Further, conventional CCS in a blue hydrogen context would likely only capture upwards of 70% of the CO2, and the rest of it would be emitted unless more sophisticated processes like oxy-fuel autothermal reforming are substituted.
To the extent that energy is necessary to convert water or methane into hydrogen, that energy could be converted into electricity and delivered directly to the wheels of an electric vehicle, instead of passing through an intermediate hydrogen chemical, losing energy with each conversion. For example, around 3× more wind turbines would need to be built in order to power a fuel cell vehicle fleet (~30% efficient) compared to an EV fleet (~90% efficient) just based on how much energy is lost along the way from wind to wheel. This is one reason why converting all of Europe’s vehicle fleet to hydrogen would consume more renewable power than its entire 2019 electricity demand.
https://cleantechnica.com/2021/02/24/hydrogen-is-big-oils-last-grand-scam/
In December, the federal government released The Hydrogen Strategy for Canada, which boasts that due to our energy economy, thriving tech sector, abundance of biomass and access to wind and solar energy, Canada is well-positioned to become one of the world’s top three producers of clean hydrogen.
It also says the strategy could help Canada reach its net-zero emissions targets, generate 350,000 high-paying jobs nationally and fuel economic opportunities.
“All over the world, people are very excited about hydrogen. They’re excited about the fact that it’s zero-emission, and that it could fill in in places where electrification is harder — particularly in the transportation sectors,” said Seamus O’Regan, the country’s minister of Natural Resources, in an interview with What on Earth host Laura Lynch.
“Heavy-duty industrial projects, maritime shipping, 18-wheelers, freight, trains — these are all big emitters. Hydrogen may help us get to that happy place where they are fuelled by a non-emitting power source.”
Energy experts argue this happy place is still a long way off.
Currently, hydrogen fuel is colour-coded. Grey hydrogen is made using fossil fuels such as natural gas; blue hydrogen is also made using fossil fuels, but the carbon emissions are captured and stored; and green hydrogen is made using renewable power such as wind, solar and hydro.
Almost all grey and blue hydrogen requires a process called steam-methane reforming, which uses steam to produce hydrogen from natural gas. Green hydrogen is most often made using electrolysis, which breaks water into hydrogen and oxygen.
According to Tahra Jutt, director of clean economy at the Pembina Institute, most of the hydrogen produced in Canada right now is grey, with a small percentage of blue.
https://www.cbc.ca/news/technology/what-on-earth-hydrogen-canada-grey-blue-green-1.5979923
Using hydrogen fuel risks locking in reliance on fossil fuels, researchers warn | Hydrogen power | The Guardian
http://www.theguardian.com/environment/2021/may/06/hydrogen-fuel-risks-reliance-on-fossil-fuels
‘Expensive distraction’: Chair of UK Hydrogen and Fuel Cell Association resigns citing blue hydrogen concerns | BusinessGreen News
https://www.businessgreen.com/news/4036010/expensive-distraction-chair-uk-hydrogen-fuel-cell-association-resigns-citing-blue-hydrogen-concerns
Biden-backed ‘blue’ hydrogen may pollute more than coal, study finds | Hydrogen power | The Guardian
http://www.theguardian.com/environment/2021/aug/12/clean-fuel-blue-hydrogen-coal-study
Hydrogen’s future as energy source remains murky despite home heating projects in Alberta and Ontario | CBC News
https://www.cbc.ca/news/canada/edmonton/hydrogen-energy-alberta-ontario-1.5828216
Amid the excitement, it is worth being clear about what hydrogen can and cannot do. Japanese and South Korean firms are keen to sell cars using hydrogen fuel cells, but battery cars are roughly twice as energy efficient. Some European countries hope to pipe hydrogen into homes, but heat pumps are more effective and some pipes cannot handle the gas safely. Some big energy firms and petrostates want to use natural gas to make hydrogen without capturing the associated carbon effectively, but that does not eliminate emissions.
Instead, hydrogen can help in niche markets, involving complex chemical processes and high temperatures that are hard to achieve with electricity. Steel firms, spewing roughly 8% of global emissions, rely on coking coal and blast furnaces that wind power cannot replace but which hydrogen can, using a process known as direct reduction. Hybrit, a Swedish consortium, sold the world’s first green steel made this way in August.
Instead, hydrogen can help in niche markets, involving complex chemical processes and high temperatures that are hard to achieve with electricity. Steel firms, spewing roughly 8% of global emissions, rely on coking coal and blast furnaces that wind power cannot replace but which hydrogen can, using a process known as direct reduction. Hybrit, a Swedish consortium, sold the world’s first green steel made this way in August.
https://www.economist.com/leaders/2021/10/09/hydrogens-moment-is-here-at-last
The fact that the enthusiasm dates back so far, though, has become an energy industry joke: “Hydrogen is the fuel of the future—and it always will be.” The problem is that there is no natural source of hydrogen; on Earth, most of it is bound up with other molecules like those of fossil fuels, or biomass, or water. The laws of thermodynamics dictate that making hydrogen from one of these precursors will always require putting more energy in than you will get out when you use the hydrogen. That is why hydrogen is today used for processes where chemically adding hydrogen atoms to things is of the essence, such as the manufacture of ammonia for fertilisers and explosives. Only in very niche applications, such as the highest-performance rocket motors, is it burned as a fuel.
https://www.economist.com/briefing/2021/10/09/creating-the-new-hydrogen-economy-is-a-massive-undertaking
Many grids have access to “pumped-hydro” plants in which water from a reservoir is used to drive turbines when extra power is needed and pumps then refill the reservoir when power is plentiful. If your grid area has the sort of mountains that provide valleys at a significant elevation (think Norway, or the foothills of the Himalayas) this technology can do a lot. But storage far from the cities of the plains is not ideal. And a big pumped-hydro plant can store maybe ten gigawatt-hours of power. When a deficit is in the tens of gigawatts and lasts for weeks, something more is needed.
The “something more” of choice, according to most analysis, is hydrogen made by electrolysis—the splitting apart of the hydrogen and oxygen in water molecules. Such hydrogen can be stored until extra power is needed, at which point it can be burned in a turbine—a process that, unlike burning natural gas, releases no carbon dioxide. Such stores can provide a lot of energy. The designers of the Advanced Clean Energy Storage Project in Delta, Utah, think that they can store 300gwh of hydrogen in one pair of salt caverns. That alone is equivalent to half as much storage capacity as that which all the world’s Li-ion battery factories provided last year.
https://www.economist.com/technology-quarterly/2023/04/05/it-is-harder-for-new-electric-grids-to-balance-supply-and-demand
